Specs
- Weight: 2,535 lbs (1,150 kg)
- Size: 120″ L × 64″ W × 78″ H
(304.8 cm L × 162.6 cm W × 198.1 cm H) - Diameter: 64″ (162.6 cm)
- Length: 120″ (304.8 cm)
- Operating Pressure: 2.0 ATA | 15 PSI | 100 kPa
- Selectable Pressures: 1.3 / 1.6 / 1.8 / 2.0 ATA
- Material: 4 mm thick 304-grade stainless steel
- Air Compressors: 2 × 120 LPM units (dual redundant)
- Oxygen Generators: High-pressure 2 × 10 LPM (customizable up to 20 LPM total)
- Oxygen Amplifiers: 2 × included
- Layout Options: Configurable for 1, 2, 3, or 4-person setup (exercise equipment, recliners, beds, bucket seats, business-class chairs)
- Display: Advanced AI touchscreen control system (interior and exterior)
- Monitoring: Pressure, air temperature, humidity, and oxygen percentage
- Noise Level: < 60 dB
- Door Type: Easy-slide large polycarbonate cabin door — activated by pressure, automatic release on depressurization
- Operation: Continuous-duty capable (ideal for clinics & doctor offices)
- Single-Operator Use: Can be operated without a second person
- Interior Features: Starlight ceiling, negative ionization system, grounding mat, communication interphone
- Warranty: 3 Years
Integrated Smart Controller / Redundant Compressor System
- Weight: 188 lbs (85 kg)
- Power: 1300 Watts
- Size: 36″ L × 19″ W × 49″ H
(91.4 cm L × 48.3 cm W × 124.5 cm H)
Oxygen Concentrator System
- Total Oxygen Flow: 20 LPM @ 60 PSI
- Air Flow: 240 LPM
- Compressor Type: Oil-free air compressor system
- Technology: PSA molecular sieve high technology
- Filters:
- Super absorption activated filters
- Double inlet and outlet filtration system
- Integrated Dehumidifier: Yes
- Noise Level: Quiet operation with built-in noise reduction
- Eco-Friendly: Non-toxic materials
- Oxygen Supply: Two continuous-flow oxygen generators included (no external oxygen tank required)
Electrical
- Voltage: 110–120V
(220V available upon request)
Certifications
- CE
- ISO 9001
- ISO 14001
- ISO 13485
- ASME-certified manufacturing facility
Climate Control System
- Air Conditioning: Complimentary — included at no additional cost
- Water Temperature Range: 5–30°C
- Features: Precise temperature regulation, integrated dehumidifier
Grounding System
- Enhances safety in highly oxygenated environments
- Effectively dissipates electromagnetic fields (EMF)
- Reduces human EMF exposure
- Promotes a more peaceful and balanced therapy session
